(Use Group)

B

C

D

(Rated Voltage) [V]

300

300

(Rated Current) [A]

8

10

(Wire Range)

(solid/Standed) [AWG]

28-16

(Withstanding Voltage)

1600V/1Min

IEC

IEC(Technical Data)

(Overvoltage Category)

|||

|||

||

(Contamination Class)

3

2

2

(Rated Voltage) [V]

250

400

500

(Rated Current) [A]

15

15

15

(Impulse wiithstand voltagea) [KV]

4.0

4.0

4.0

(Conductor cross section)

(Solid/flexible)  [mm²]

0.2-1.5

(Material)

(Insulation Material)

PA66

(Imflammability)

UL94V-0

(Contactor Material)

铜合金(Copper alloy)

(Contactive Coating)

镀锡(Tin Plated)

(Other Data)

(Pitch) [mm]

5.0

Poles) [P]

3*(2~24)

(Stripping Length) [mm]

8~9

(ScrewTorque Max) [N.m]

(Operating temperatur)  [℃]

-40~+105

(PCB Hole Diameter)  [mm]

1.4
