间距/极数 Pitch/Poles [mm]/[P]

2.54/1~30

剥线长度 Stripping Length [mm]

11

工作温度 Operating temperature [℃]

-40~+105

焊锡温度 Soldering temperature

250℃/5S

引针尺寸 Pin dimensions [mm]

0.7*0.5

技术数据-UL/CUL

额定电压 Rate Voltage [V]

300

额定电流 Rated Current [A]

15

接线范围 Wire Range [AWG]

28~12

耐电压 Dielectric Voltage-Withstand

1.6KV

材料 Material

绝缘材料 Insulation Material

PA66

阻燃等级 Flame relardant rating

UL94V-0
